RIGID-IMC FITTINGS
Are you looking for ease of
installation and durability on your next jobsite?
Check out SEPCO’s expansive catalog of Rigid/IMC fittings. From junction conduit outlet boxes, FS & FD device boxes and covers, compression and set-screw connectors and couplings, as well as multiple insulated bushings, you are sure to find the electrical fitting you need.
Contact SEPCO today.
MALLEABLE IRON CONDUIT NIPPLES
APPLICATION
Used through knockout to connect box to conduit coupling. Used with a locknut to connect two boxes side by side or back to back. Used with a locknut to connect fixture housing to continuous runs.
FEATURES
- Available with insulated Throat.
- With rigid conduit threads (NPS)
STANDARD MATERIALS
Malleable Iron
STANDARD FINISH
Zinc Plated
UL LISTED
E198258
| Catalog Number | Trade Size | Unit Pack | Master Pack | UPC | |
|---|---|---|---|---|---|
| 90 | 1/2” | 100 | 1000 | 19001 | View details |
| 91 | 3/4” | 100 | 1000 | 19101 | View details |
| 92 | 1” | 50 | 500 | 19201 | View details |
| 93 | 1-1/4” | 25 | 250 | 19301 | View details |
| 94 | 1-1/2” | - | 25 | 19401 | View details |
| 95 | 2” | - | 25 | 19501 | View details |
| 96 | 2-1/2” | - | 15 | 19601 | View details |
| 97 | 3” | - | 10 | 19701 | View details |
| 98 | 3-1/2” | - | 10 | 19801 | View details |
| 99 | 4” | - | 10 | 19901 | View details |
| 995 | 5” | - | 5 | 19951 | View details |
| 996 | 6” | - | 5 | 19961 | View details |
